Description
Title :- Model 9123 Single-Ended Beam Load Cell
Brand :- Revere
DESCRIPTION
Model 9123 is a low-profile single-ended shear beam type load cell and is made from stainless steel.
This load cell is suitable for small and medium platform scales, overhead track scales, hopper scales, and process weighing applications.
Reliable sealing is ensured by the proprietary TRANSEAL
potting compound and additional mechanical protection
of the strain gage area.
Ease of installation is made possible through the use of a partially-threaded hole to accept levelling feet, load buttons, or loading cables.
FEATURES
Capacities: 5005000 kg, 1k20k lbs.
Low-profile construction
Certified to OIML R-60, 4000d and NTEP III,
5000 divisions
Sealing: IP67 (DIN 40.050)
Stainless-steel construction
Threaded load hole
Optional
– FM certified for use in potentially explosive
atmospheres
APPLICATIONS
Low profile platforms
Pallet truck weighing
Tank and silo weighing
