Title :- Model HBB Hermetically-Sealed Bending Beam
Brand :- Tedea-Huntleigh
DESCRIPTION
The Model HBB is a single-ended bending beam load cell designed for multiple cell applications, such as low profile platform scales or small tank scales, when used with proper mounting accessories. It is insensitive to side load and capable of reversed loading.
The Model HBB is constructed of stainless steel or alloy steel. The strainless steel version is hermetically-sealed to IP68, providing excellent protection against corrosive and wash-down environments.
FEATURES
Capacities: 10, 20, 30, 50, 75, 100, 200 and 250 kg
Stainless steel or alloy steel construction
Stainless steel version hermetically-sealed
High side load tolerance
Easy installation
OIML C3 approval from 50 kg to 250 kg
APPLICATIONS
Platform scales (multiple load cells)
Silo / hopper / tank weighing
Packaging machines
Dosing / filling
Belt scales / conveyor scales
